Tourismo Euro V
Technical Data
Technical data at a glance.
| Passenger capacity | |
| Seats arrangement – 3*: | 1/1/51 |
| Seats arrangement – 4*: | 1/1/46 |
| Dimensions | |
| Length (mm) | 12.140 |
| Width (mm) | 2.550 |
| Height incl. AC unit (mm) [1] | approx. 3.620 |
| Distance between the axles (front – drive) (mm) | 6.080 |
| Distance between the axles (drive – rear) (mm) | - |
| Tyre size | 295/80 R 22.5 |
| Front overhang (mm) | 2.760 |
| Rear overhang (mm) | 3.300 |
| Front overhang angle (°) | 7,65 |
| Rear overhang angle (°) | 6,9 |
| External turning diameter (mm) | approx. 20.980 |
| Engine & capacity | |
| Engine (standard) | Mercedes-Benz OM 457 hLA |
| Emission standards (exhaust gases) | Euro V |
| System | Completely electronic with direct injection pumps |
| Maximum capacity (kW [hp] at rev./min.) | 260 |
| Actual volume (cm³) | 11.967 |
| Number and arrangement of cylinders | 6 / row, horizontal arrangement |
| Rated load torque (Nm at rev./min.) | 1.600 Nm at 1.100/min. |
| Transmission (standard), type | 6-speed Mercedes-Benz, GO 190, with servo drive |
| Engine & capacity (special option) | |
| Engine 2 (special option) | Mercedes-Benz OM 457 hLA |
| Emission standards (exhaust gases) (Engine 2) | Euro V |
| Maximum capacity (kW [hp] at rev./min.) (Engine 2) | 300 |
| Actual volume (cm³) (Engine 2) | 11.967 |
| Number and arrangement of cylinders (Engine 2) | 6 / row, horizontal arrangement |
| Rated load torque (Nm at rev./min.) (Engine 2) | 1.900 Nm at 1.100/min. |
| Transmission (Engine 2) | GO 240-8 or ZF AS-Tronic |
| Chassis | |
| Steering control | ZF 8098 Servocom |
| Front axle, type | Independent suspension ZF |
| Drive axle, type | Mercedes-Benz HO6 |
| Rear axle, type | - |
| Brakes | |
| Primary braking system | Disc brakes |
| Brake retarder | ✔ |
| Electronic braking system control (EBS) | ✔ |
| Auxiliary systems | |
| Anti-lock Brake System (ABS) | ✔ |
| Traction control system (ASR) | ✔ |
| Electronic system of motion stabilisation (ESP®) | ✔ |
| Emergency braking system (BAS) | ✔ |
| Reversing assistance | - |
| Weight | |
| Fuel tank capacity for diesel engine (l) | approx. 490 |
| Tank capacity for AdBlue (l) | approx. 61 |
| Empty weight (kg) [2] | approx. 13.400 |
| Vehicle rated weight (kg) [3] | 18.000 |
| Front axle (kg) | 7.100 |
| Drive axle (kg) | 11.500 |
| Rear axle (kg) [4] | - |
| Doors | |
| Height, door 1 (mm) | 2.300 |
| Height, door 2 (mm) | 1.840 |
| Door height, front (mm) | 2.200 |
| Door height, rear (mm) | 1.815 |
| Door width, front (mm) | 770 |
| Door width, middle (mm) | 770 / or depending on the seats arrangement 590-650 |
| Clearance height, door 1 (mm) | approx. 350 |
| Clearance height, door 2 (mm) | approx. 325 |
| Stair step height, door 1 (mm) | 3x170 + 2x178 |
| Driver's place floor height against the road (mm) | 860 |
| Central aisle floor height against the road (mm) | ок. 1.330 |
| Stair-case floor height against the central aisle floor (mm) | 150 |
| Handrails height (installed on the raised area) (mm) | 750 |
| Stair step height in the centre, door 2 (mm) | 4 x 250 |
| Air-conditioning system | |
| Passenger compartment cooling capacity (kW) | 32 |
| Passenger compartment heat range (kW) | 38 |
| Driver's place cooling capacity (kW) | 8 |
| Driver's place heat range (kW) | 18 |
| Luggage storage capacity | |
| Luggage storage capacity (m³) | approx. 9,6 |
| Luggage storage capacity (m³) in case the bathroom is available | approx. -1,2 |
| Luggage storage capacity (m³) in case the bathroom and driver's rest room are available | approx. -1,4 |
