Tourrider Premium & Business: All Facts & Figures

All Facts & Figures


Dimensions
Length [ft/mm]	45' 8" / 13,920	45' 8" / 13,920
Width [ft/mm]	102" / 2,600	102" / 2,600
Height [ft/mm]	12' 1" / 3,745	11' 11" / 3,685
Wheelbase front axle-drive axle [ft/mm]	24' / 7,315	24' / 7,315
Wheelbase drive axle - trailing axle [ft/mm]	4' 5" / 1,350	4' 5" / 1,350
Tire size	315/80R22.5	315/80R22.5
Turning radius [ft/mm]	39' 11" / 12,170	39' 11" / 12,170
Powertrain
Engine	Mercedes-Benz OM 471	Mercedes-Benz OM 471
Engine type	In-line six-cylinder	In-line six-cylinder
Output [hp/kW]	450 / 336	450 / 336
Max. torque [Ibft/Nm]	1,550 / 2,102	1,550 / 2,102
Automatic Powertrain with retarder	Allison WTB 500R	Allison WTB 500R
Chassis
Front axle, type	ZF, independent wheel suspension	ZF, independent wheel suspension
Driven axle, type	Mercedes-Benz RO 440	Mercedes-Benz RO 440
Trailing axle, type	ZF, independent wheel suspension	ZF, independent wheel suspension
Raising/Lowering system	●	●
Kneeling	●	●
Brakes
Pneumatic disc brakes on all axles (Knorr)	●	●
Electronic Stability Program (ESP®)	●	●
Electronically controlled braking system (EBS)	●	●
Anti-lock braking system (ABS)	●	●
Brake Assist (BAS)	●	●
Traction Control	●	●
Safety and driver assistance systems
Adaptive Cruise Control (ACC)	●	○
Lane Departure Warning (LDW)	●	●
Attention Assist (AtAs)	○	○
Tire Pressure Monitoring (TPM)	○	○
Active Brake Assist 5 (ABA 5)	● (with Adaptive Cruise Control)	●
Front Collision Guard (FCG)	●	●
Sideguard Assist	○	○
Electronic Stability Program (ESP®)	●	●
Reversing camera	○	○
Rain-light sensor	●	○
360° camera	○	○
Transport capacity
Number of seats– Standard seating	56	56
Passenger capacity max.	60	60
Seating type Travel Star Eco (TSE)	-	●
Seating type Travel Star Eco (TSE) Softline	-	○
Seating type Travel Star Xtra (TSX)	●	○
Seating type Travel Star Xtra (TSX) Softline	○	○
Seating type Travel Star Xtra (TSX) Luxline	○	-
Driver’s seat ISRI 6860, integrated pneumatic system, 3-point seat belt	●	●
ADA (lift)	○	○
Weight and fuel tanks
Fuel Capacity [gal/l]*	225.7 / 854.4	225.7 / 854.4
DEF Capacity [gal/l]	14 / 53	14 / 53
Gross vehicle weight [lbs/kg]	50,535 / 22,922	50,535 / 22,922
Axle loads, max. permissible front axle [lbs/kg]	16,535 / 7,500	16,535 / 7,500
Axle loads, max. permissible drive axle [lbs/kg]	20,000 / 9,072	20,000 / 9,072
Permissible weight trailing axle [lbs/kg]	14,000 / 6,350	14,000 / 6,350
Doors and glazing
Lift	○	○
Double glazed side windows	●	●
Windscreen heatable	○	○
Lighting
Low beam (LED)	●	●
High beam (LED)	●	●
Daytime driving lights with LED technology	●	●
Headlamps with LED technology	●	●
Front fog lamp	●	●
Cornering light	●	●
Ambient lighting luggage compartment	○	○

*only 95% useable by US regulation

● Standard equipment
○ Optional equipment

Changes may have been made to the data since the copy deadline of this product information. This data sheet only provides a selection of equipment/ appointments available. Please consult your Mercedes-Benz regional sales manager for final details.
